DrMUTT

(Dual Role Multipurpose USB Test Tool)

 Supports USB Host and Device modes.

o USB 2.0 Host Mode.

- ID pin is floated so device under test will be in device mode.

- DrMUTT provides VBUS

o USB 2.0 Device Mode.

- ID pin is grounded so device under test will be in host mode.

- Device under test provides VBUS

 Utilizes a Cypress EZ-USBR FX3 SuperSpeed USB Controller

o USB 2.0 peripheral compliant.

o Thirty-two physical endpoints

o ARM926EJS core with 200 MHz operation

o 512KB Embedded SRAM

o Supports Control, Interrupt, Bulk, Isochronous and streams data transfers.

 Right angle USB Mico B Male connector

 Self powered device.

 Onboard +3.3V, +1.2v Voltage Regulators

 Two SPI 2MB EEPROMs, and 32KB SPI RAM.

 Watchdog timer

 Thumb drive form factor -- tiny only 3 x 0.8 inches
